Main Applications
• Light source for optical fiber illumination
Specifications
-
Default Settings
-
Input voltage switch: 115 display AC cable: MC-AC100A-2.0M
-
Input Voltage
-
AC100 to 120 V/ 200 to 240 V (50/ 60 Hz)
-
Input Voltage Switching Method *1
-
With AC 100 input: Set to 115 display
With AC 200 input: Set to 230 display
-
Input Current (typ)
-
2.4 A (with AC 100 V input)
1.2 A (with AC 200 V input)
-
Lamp Voltage
-
DC 11.7 V ±0.2 V (max.)
-
Average Lamp Life *2
-
1,000 hours nominal
-
Average Illuminance *3
-
Approx. 30,000 Lx
-
Installation Method
-
Horizontal installation with the rubber feet on the bottom facing down
-
Operating Temperature/ Humidity
-
0°C to 45°C
80% RH up to 31°C, 50% RH up to 40°C
-
Safety Standards *4
-
EN61010:2001 EN61000-6-2:2001/ EN55011:1998, A1:1999, A2:2002
-
Notes
-
With external digital light intensity control & built-in shutter (normally open)
* Lamps other than compatible lamps cannot be used.
Accessories
-
External remote connector with cable
-
MC-EXC-02
-
External remote connector
-
D-SUB155
