Applicable magnification when spacer is installed
-
MODEL NAME
-
SPACER TYPE
-
MAGNIFICATION (x)
-
WD (mm)
-
FFD (mm)
-
ML-F80C-0205
-
A (REVERS)※1
-
0.2~0.37
[0.45~0.5]※2
-
476.8~282.6
[242.0~223.2]※2
-
78.6~92.9
[99.7~103.9]※2
-
ML-F80C-0205
-
A
-
0.37~0.5
[Not available]※2
-
282.6~223.2
[Not available]※2
-
92.9~103.9
[Not available]※2
-
ML-F80C-0510
-
A(REVERS)※1
-
Not available
[0.58~0.65]※2
-
Not available
[196.3~180.3]※2
-
Not available
[99.9~105.8]※2
-
ML-F80C-0510
-
A
-
0.5~0.67
[0.75~0.82]※2
-
220.1~176.3
[162.5~152.6]※2
-
93.0~107.5
[114.3~120.2]※2
-
ML-F80C-0510
-
B
-
0.67~0.83
[0.92~1.0]※2
-
176.3~151.3
[140.9~133.3]※2
-
107.5~121.1
[128.6~135.3]※2
-
ML-F80C-0510
-
C
-
0.83~1.0
[Not available]※2
-
151.3~133.3
[Not available]※2
-
121.1~135.3
[Not available]※2
※1 Connect Spacer A in reverse.
※2 The figures in brackets [ ] are for when CA-V74FMT is installed.
